5.4.2
Group Shift in User & Macro Mode
To navigate to User & Macro Mode, the user code should be registered or the macro function
should be selected. If the user code is registered and the macro function is selected, you can
navigate to the group as shown below.
• Displays when the inverter is powered on. This is
the display of Monitor mode (MON).
• Press the [MODE] key twice.
• You are now in the User & Macro mode (U&M).
• The User Group (USR) is displayed.
• Press the [Right] key.
• You are now in the Macro group (MC1).
• Press the [Right] key.
• You are now in the User Group (USR) again.
