LSIS SV-IS7 User Manual

Basic Functions
127
Basic
Functions
6.3 Changing the Displayed Units (Hz↔Rpm)
You can change the units used to display the operational speed of the inverter by setting DRV-
21 (Speed unit selection) to “0 (Hz Display)” or “1 (Rpm Display)”.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV
21
Speed unit
selection
Hz/Rpm Sel
0
Hz Display
0–1
-
1
Rpm Display
6.4 Setting Multi-Step Frequency
Multi-step operations can be carried out by assigning different speeds (or frequencies) to the
Px terminals. Step 0 uses the frequency reference source set at DRV-07. Px terminal parameter
values 7 (Speed-L), 8 (Speed-M), 9 (Speed-H), and 10 (Speed-X) are recognized as binary
commands and work in combination with Fx or Rx run commands. The inverter operates
according to the frequencies set at BAS-50–64 (multi-step frequency 1–15) and the binary
command combinations.
Group
Code
Name
LCD Display
Parameter
Setting
Setting Range
Unit
DRV
07
Frequency
reference source
Freq Ref Src
-
-
-
BAS
50–64
Multi-step
frequency 1–15
Step Freq - x
-
-
Hz
IN
65–75
Px terminal
configuration
Px Define (Px: P1–
P8 [optional: P9–
P11]) [Optional
P9–P11]
7
Speed-L
0–51
-
8
Speed-M
-
9
Speed-H
10
Speed-X
-
89
Multi-step
command delay
time
InCheck Time
1
1–5000
ms
