Table of Functions
200
8.16 User/Macro mode – Traverse Operation Function
Group (MC2)
Traverse Operation Function Group (U&M  MC2)
No.
LCD Display
Name
Setting Range
Initial Value
00
Jump Code
Jump code
0–99
1
01
Acc Time
Acceleration time
0–600 (sec)
Below 75 kW
20
Above 90 kW
60
02
Dec Time
Deceleration time
0–600 (sec)
Below 75 kW
30
Above 90 kW
90
03
Cmd Source
Command source
0–5
1:Fx/Rx-1
04
Freq Ref Src
Frequency reference source
0–9
0:Keypad-1
05
Control Mode
Control mode
0–5
0:V/F
06
App Mode
Applied function selection
0–4
1:Traverse
07
Trv Apmlit %
Traverse operating range
0–20 (%)
0.0
08
Trv Scramb %
Traverse scramble magnitude
0–50 (%)
0.0
09
Trv Acc Time
Traverse acceleration time
0.1–600 (sec)
2.0
10
Trv Dec Time
Traverse deceleration time
0.1–600 (sec)
2.0
11
Trv Offset Hi
Traverse offset upper limit
0–20 (%)
0.0
12
Trv Offset lo
Traverse offset lower limit
0–20 (%)
0.0
13
P1 Define
P1 terminal function setting
0–48
0:FX
14
P2 Define
P2 terminal function setting
0–48
1:RX
15
P3 Define
P3 terminal function setting
0–48
5:BX
16
P4 Define
P4 terminal function setting
0–48
27:Trv
17
P5 Define
P5 terminal function setting
0–48
28:Trv
