Peripheral Devices
9.1.2 Reactors
DC Reactor Specifications
The iS7 200 V / 400V 30–75 kW, 400 V/280–375 kW models are not supplied with a built-in DC
reactor. Refer to the following specifications tables for different models to choose an
appropriate DC reactor for your application.
<200V/30–75kW>
Inverter capacity
DC reactor specifications
mH
A
0300iS7-2
0.24
200
0370iS7-2
0.2
240
0450iS7-2
0.17
280
0550iS7-2
0.12
360
0750iS7-2
0.1
500
<400V/30–75kW>
(For Non-DCR products, remove the P1 and P2 shorting pins to install the DC reactor.)
Inverter capacity
DC reactor specifications
mH
A
0300iS7-4
0.98
75
0370iS7-4
0.87
90
0450iS7-4
0.55
110
0550iS7-4
0.47
150
0750iS7-4
0.48
180
<400V/280–375 kW>
Inverter capacity
DC reactor specifications
mH
A
2800iS7-4
0.09
836
3150iS7-4
0.076
996
3750iS7-4
0.064
1195
Note
All iS7 models, other than the 200 V/30–75 kW and 400 V/280–375 kW models, may be provided with
an optional built-in DC reactor.
