8.11 Parameter Mode – Protective Function Group
(PRT)
Protective Function Group (PAR  PRT)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
00
-
Jump Code
Jump code
0 – 99
40
O
O
O
O
O
O
04
0h1B04
Load Duty
Load amount setting
0
Normal Duty
1:Heavy
Duty
X
O
O
O
O
O
1
Heavy Duty
05
0h1B05
Phase Loss Chk
Input/output open-
phase protection
Bit
00 – 11
00
X
O
O
O
O
O
1
Output open phase
2
Input open phase
06
0h1B06
IPO V Band
Input voltage range
during open-phase
1 – 100 (V)
40
X
O
O
O
O
O
07
0h1B07
Trip Dec Time
Deceleration time at
fault trip
0 – 600 (sec)
3.0
O
O
O
O
O
O
08
0h1B08
RST Restart
Starting selection on
trip reset
0
No
0:No
O
O
O
O
O
O
1
Yes
09
0h1B09
Retry Number
Number of
automatic restarts
0 – 10
0
O
O
O
O
O
O
10
Note40)
0h1B0A
Retry Delay
Automatic restart
delay time
0 – 60.0 (sec)
1.0
O
O
O
O
O
O
11
0h1B0B
Lost KPD Mode
Keypad command
loss operation mode
0
None
0:None
O
O
O
O
O
O
1
Warning
2
Free-Run
3
Dec
12
0h1B0C
Lost Cmd
Mode
Speed command
loss operation mode
0
None
0:None
O
O
O
O
O
O
1
Free-Run
2
Dec
3
Hold Input
4
Hold Output
5
Lost Preset
13
Note41)
0h1B0D
Lost Cmd Time
Speed command
loss judgment time
0.1 – 120 (sec)
1.0
O
O
O
O
O
O
14
0h1B0E
Lost Preset F
Operation frequency
at speed command
loss
Start frequency
– maximum frequency
(Hz)
0.00
O
O
O
O
O
O
15
0h1B0F
AI Lost Level
Analog input
loss judgment level
0
Half of x1
0:Half of
x1
O
O
O
O
O
O
1
Below x1
17
0h1B11
OL Warn Select
Overload alarm
selection
0
No
0:No
O
O
O
O
O
O
1
Yes
18
0h1B12
OL Warn Level
Overload alarm level
30 – 180 (%)
150
O
O
O
O
O
O
19
0h1B13
OL Warn Time
Overload alarm time
0 – 30.0 (sec)
10.0
O
O
O
O
O
O
20
0h1B14
OL Trip Select
Motion at overload
trip
0
None
1:Free-
Run
O
O
O
O
O
O
1
Free-Run
2
Dec
