Connecting the Cables
50
4.1.2 IP 54 Type Products
1 Loosen the two screws securing the keypad cover, and then remove the keypad cover.
2 Depress the tab at the top of the keypad and gently lift the keypad from the inverter to
remove it. Be careful not to damage the keypad cable.
3 Depress the tab on the keypad cable connector and disconnect the cable from the back of
the keypad.
