LSIS SV-IS7 - Exterior and Dimensions (UL Enclosed Type 1, IP21 Type)

Installing the Inverter
Installing
the Inverter
21
3.3 Exterior and Dimensions (UL Enclosed Type 1, IP21
Type)
SV0008-0037iS7 (200 V/400 V)
Units: mm (inch)
Inverter Capacity
W1
W2
H1
H2
H3
D1
A
B
SV0008–0037 iS7 - 2/4
150
(5.90)
127
(5.00)
284
(11.18)
257
(10.11)
18
(0.70)
200
(7.87)
5
(0.19)
5
(0.19)
