6.5.4 RS-485 Communication as a Command Input Device
Internal RS-485 communication can be selected as a command input device by setting DRV-06
(command source) in the Drive group to “3 (Int 485)”. This configuration uses upper level
controllers, such as PCs or PLCs, to control the inverter by transmitting and receiving signals via
the S+, S-, and RS-485 signal input terminals at the terminal block.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV
06
Command source
Cmd Source
3
Int 485
0–5
-
COM
04
Integrated
communication
inverter ID
Int485 St ID
1
1–250
-
05
Integrated
communication
protocol
Int485 Proto
0
ModBus RTU
-
-
06
Integrated
communication speed
Int485 BaudR
3
9600 bps
1200–38400
bps
07
Integrated
communication frame
setup
Int485 Mode
0
D8 / PN / S1
-
-
6.6 Forward or Reverse Run Prevention
The rotation direction of motors can be configured to prevent motors from running in a
forward or reverse direction. When reverse direction prevention is configured, pressing the
[REV] key on the keypad will cause the motor to decelerate to 0 Hz and stop.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
ADV
09
Run prevention
options
Run Prevent
0
None
0–2
-
1
Forward
Prev
2
Reverse
Prev
