Table of Functions
Function
Table
199
8.15
User/Macro Mode Draw Operation Function
GroupMC1
U&M MC1
No.
LCD Display
Name
Setting Range
Initial Value
00
Jump Code
Jump code
0
99
1
01
Acc Time
Acceleration time
0
600 (sec)
Below 75 kW
20
Above 90 kW
60
02
Dec Time
Deceleration time
0
600 (sec)
Below 75 kW
30
Above 90 kW
90
03
Cmd Source
Command source
0
5
1:Fx/Rx-1
04
Freq Ref Src
Frequency reference source
0
9
2:V1
05
Control Mode
Control mode
0
5
0:V/F
06
Aux Ref Src
Auxiliary reference source
0
4
2:I1
07
Aux Calc Type
Auxiliary calculation type
0
7
0
08
Aux Ref Gain
Auxiliary reference gain
-200
200 (%)
100.0
09
V1 Polarity
V1 input polarity selection
0
1
0:Unipolar
10
V1 Filter
V1 input filter time constant
0
10000 (ms)
10
11
V1 Volt x1
V1 minimum input voltage
0
10 (V)
0.00
12
V1 Perc y1
Output at V1 minimum voltage (%)
0
100 (%)
0.00
13
V1 Volt x2
V1 maximum input voltage
0
10 (V)
10.00
14
V1 Perc y2
Output at V1 maximum voltage (%)
0
100 (%)
100.00
15
V1 Volt x1
V1 minimum input voltage
-10
0 (V)
0.00
16
V1 Perc y1
Output at V1 minimum voltage (%)
-100
0 (%)
0.00
17
V1 Volt x2
V1maximum input voltage
-10
0 (V)
-10.00
18
V1 Perc y2
Output at V1 maximum voltage (%)
-100
0 (%)
-100.00
19
V1 Inverting
Rotation direction change
0
1
0:No
20
I1 Monitor(mA)
I1 input amount display
0
20 (mA)
0.00
21
I1 Polarity
I1 polarity display
0
1
0
22
I1 Filter
I1 input filter time constant
0
10000 (ms)
10
23
I1 Curr x1
I1 minimum input current
0
20 (mA)
4.00
24
I1 Perc y1
Output at I1 minimum current (%)
0
100 (%)
0.00
25
I1 Curr x2
I1 maximum input current
4
20 (mA)
20.00
26
I1 Perc y2
Output at I1 maximum current (%)
0
100 (%)
100.00
27
I1 Curr x1
I1 minimum input current
-20
0 (mA)
0.00
28
I1 Perc y1’
Output at I1 - minimum current (%)
-1000 (%)
0.00
29
I1 Curr x2
I1 maximum input current
-200 (mA)
-20.00
30
I1 Perc y2’
Output at I1 maximum current (%)
-1000 (%)
-100.00
31
I1 Inverting
Rotation direction change
01
0:No
32
P1 Define
P1 terminal function setting
048
0:FX
33
P2 Define
P2 terminal function setting
048
1:RX
34
P3 Define
P3 terminal function setting
048
5:BX
