LSIS SV-IS7 User Manual

Table of Functions
162
8.3 Parameter Mode – Expansion Function Group
(PARADV)
Expansion Function Group (PAR  ADV)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
00
-
Jump Code
Jump code
0–99
24
O
O
O
O
O
O
01
0h1301
Acc Pattern
Acceleration pattern
0
Linear
0:Linear
X
O
O
O
X
X
02
0h1302
Dec Pattern
Deceleration pattern
1
S-curve
X
O
O
O
X
X
03
0h1303
Acc S Start
S-curve acceleration start
point gradient
1–100 (%)
40
X
O
O
O
X
X
04
0h1304
Acc S End
S-curve acceleration end
point gradient
1–100 (%)
40
X
O
O
O
X
X
05
0h1305
Dec S Start
S-curve deceleration start
point gradient
1–10 0 (%)
40
X
O
O
O
X
X
06
0h1306
Dec S End
S-curve deceleration end
point gradient
1–100 (%)
40
X
O
O
O
X
X
07
0h1307
Start Mode
Start mode
0
Acc
0:Acc
X
O
O
O
X
X
1
Dc-Start
08
0h1308
Stop Mode
Stop mode
0
Dec
0:Dec
X
O
O
O
X
X
1
Dc-Brake
2
Free-Run
3
Flux Braking
4
Power Braking
09
0h1309
Run Prevent
Selection of prohibited
rotation direction
0
None
0:None
X
O
O
O
X
X
1
Forward Prev
2
Reverse Prev
10
0h130A
Power-on Run
Start with power on
0
No
0:No
O
O
O
O
X
X
1
Yes
12
Note8)
0h130C
Dc-Start Time
Starting DC braking time
0–60 (sec)
0.00
X
O
O
O
X
X
13
0h130D
Dc Inj Level
DC supply
0–200 (%)
50
X
O
O
O
X
X
14
Note9)
0h130E
Dc-Block Time
Output blocking time
before DC braking
0–60 (sec)
0.10
X
O
O
O
X
X
15
0h130F
Dc-Brake Time
DC braking time
0–60 (sec)
1.00
X
O
O
O
X
X
16
0h1310
Dc-Brake Level
DC braking rate
0–200 (%)
50
X
O
O
O
X
X
17
0h1311
Dc-Brake Freq
DC braking frequency
Starting frequency–60 (Hz)
5.00
X
O
O
O
X
X
20
0h1314
Acc Dwell Freq
Acceleration dwell
frequency
Starting frequency
–maximum frequency (Hz)
5.00
X
O
O
O
X
X
21
0h1315
Acc Dwell Time
Acceleration dwell
operation time
0–60.0 (sec)
0.00
X
O
O
O
X
X
22
0h1316
Dec Dwell Freq
Deceleration dwell
frequency
Starting frequency
–maximum frequency (Hz)
5.00
X
O
O
O
X
X
23
0h1317
Dec Dwell Time
Deceleration dwell
operation time
0–60.0 (sec)
0.00
X
O
O
O
X
X
* The grey cells indicate a hidden code which is only visible when setting a code.
Note 8)
ADV-12 is displayed only when ADV-07 “Stop Mode” is set as “DC-Start”.
Note 9)
ADV-14 – 17 is displayed only when ADV-08 “Stop Mode” is set as “DC-Brake”.
