LSIS SV-IS7 User Manual

Table of Functions
Function
Table
193
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
21
0h1B15
OL Trip Level
Overload trip level
30 – 200 (%)
180
O
O
O
O
O
O
22
0h1B16
OL Trip Time
Overload trip time
0 – 60 (sec)
60.0
O
O
O
O
O
O
25
0h1B19
UL Warn Sel
Under load alarm
selection
0
No
0:No
O
O
O
O
O
O
1
Yes
26
0h1B1A
UL Warn Time
Under load alarm
time
0 – 600.0 (sec)
10.0
O
O
O
O
O
O
27
0h1B1B
UL Trip Sel
Under load trip
selection
0
None
0:None
O
O
O
O
O
O
1
Free-Run
2
Dec
28
0h1B1C
UL Trip Time
Under load trip time
0 – 600 (sec)
30.0
O
O
O
O
O
O
29
0h1B1D
UL LF Level
Under load lower
limit level
10 – 30 (%)
30
O
O
O
O
O
O
30
0h1B1E
UL BF Level
Under load upper
limit level
10 – 100 (%)
30
O
O
O
O
O
O
31
0h1B1F
No Motor Trip
Operation on no
motor trip
0
None
0: None
O
O
O
O
O
O
1
Free-Run
32
Note42)
0h1B20
No Motor
Level
No motor
detection current
level
1 – 100 (%)
5
O
O
O
O
O
O
33
0h1B21
No Motor Time
No motor
detection delay
0.1 – 10.0 (sec)
3.0
O
O
O
O
O
O
34
0h1B22
Thermal-T Sel
Operation at motor
overheat detection
0
None
0:None
O
O
O
O
O
1
Free-Run
2
Dec
35
0h1B23
Thermal In
Src
Thermal sensor input
0
None
0:None
O
O
O
O
O
1
V1
2
I1
3
V2
4
I2
36
0h1B24
Thermal-T Lev
Thermal sensor fault
level
0 – 100 (%)
50.0
O
37
0h1B25
Thermal-T
Area
Thermal sensor fault
area
0
Low
0:Low
O
O
O
O
O
1
High
40
0h1B28
ETH Trip Sel
Electronic thermal
fault trip prevention
selection
0
None
0:None
O
O
O
O
O
1
Free-Run
2
Dec
41
0h1B29
Motor Cooling
Motor
cooling fan type
0
Self-cool
0:Self-
cool
O
O
O
O
O
1
Forced-cool
42
0h1B2A
ETH 1min
Electronic thermal
one minute rating
120 – 200 (%)
150
O
O
O
O
O
O
43
0h1B2B
ETH Cont
Electronic thermal
prevention
continuous rating
50 – 200 (%)
120
O
O
O
O
O
O
45
0h1B2D
BX Mode
BX mode select
0 (sec)
Free-run
0.0 (Free-
run)
O
O
O
O
X
X
0.1 – 600.0
(sec)
Dec
