LSIS SV-IS7 User Manual

Table of Functions
Function
Table
191
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
66
0h1A42
PLC Wr Data 7
PLC write data 7
0 – FFFF (Hex)
0000
O
O
O
O
O
O
67
0h1A43
PLC Wr Data 8
PLC write data 8
0 – FFFF (Hex)
0000
O
O
O
O
O
O
76
0h1A4C
PLC Rd Data 1
PLC read data 1
0 – FFFF (Hex)
0000
O
O
O
O
O
O
77
0h1A4D
PLC Rd Data 2
PLC read data 2
0 – FFFF (Hex)
0000
O
O
O
O
O
O
78
0h1A4E
PLC Rd Data 3
PLC read data 3
0 – FFFF (Hex)
0000
O
O
O
O
O
O
79
0h1A4F
PLC Rd Data 4
PLC read data 4
0 – FFFF (Hex)
0000
O
O
O
O
O
O
80
0h1A50
PLC Rd Data 5
PLC read data 5
0 – FFFF (Hex)
0000
O
O
O
O
O
O
81
0h1A51
PLC Rd Data 6
PLC read data 6
0 – FFFF (Hex)
0000
O
O
O
O
O
O
82
0h1A52
PLC Rd Data 7
PLC read data 7
0 – FFFF (Hex)
0000
O
O
O
O
O
O
83
0h1A53
PLC Rd Data 8
PLC read data 8
0 – FFFF (Hex)
0000
O
O
O
O
O
O
* The grey cells indicate a hidden code which is only visible when setting a code.
Note 37)
APO-01 – 14 codes are displayed only when the encoder module is installed.
Note 38)
APO-20 – 42 codes are displayed only when APP-01 (App Mode) is set as “MMC”.
Note 39)
APO-58 – 83 codes are displayed only when the PLC option module is installed.
