LSIS SV-IS7 User Manual

Basic Functions
122
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
maximum V2’
voltage
46
Invert V2 rotational
direction
V2 Inverting
No
No/Yes
-
47
V2 quantizing level
V2
Quantizing
0.04
0.00*, 0.04–
10.00
%
* Quantizing is disabled if “0” is selected.
6.1.4.2 Setting a Reference Frequency using Input Current at I2 Terminal
Set the DRV-07 (Frequency reference source) to “5 (I2)” and apply an input voltage of 0–20 mA
to the I2 terminal.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV
07
Frequency reference
source
Freq Ref Src
5
I2
0–9
-
50
I2 input monitor
I2 Monitor
0.00
0.00–20.00
mA
52
I2 input filter time
constant
I2 Filter
10
0–10000
ms
53
I2 minimum input
current
I2 Curr x1
4.00
0.00–20.00
mA
54
I2 output at
minimum current (%)
I2 Perc y1
0.00
0–100
%
55
I2 maximum input
current
I2 Curr x2
20.00
4.00–20.00
mA
56
I2 output at
maximum current (%)
I2 Perc y2
100.00
0.00–100.00
%
61
I2 rotation direction
options
I2 Inverting
0
No
0–1
-
62
I2 quantizing level
I2
Quantizing
0.04
0.00*, 0.04–
10.00
%
* Quantizing is disabled if “0” is selected.
