Set the acc/dec time based on the operating frequency.
If, for example, the maximum frequency is 60.00 Hz, the acc/dec times are set
to 5 seconds, and the frequency reference for operation is set at 30 Hz (half of
60 Hz). Therefore, the time required to reach 30 Hz is 2.5 seconds (half of 5
seconds).
Use the time scale for all time-related values. It is particularly useful when
more accurate acc/dec times are required, due to load characteristics, or
when the maximum time range needs to be extended.
Sets 0.01 second as the minimum unit.
Sets 0.1 second as the minimum unit.
Sets 1 second as the minimum unit.
Note that the range of maximum time values may change automatically when the units are
changed. If for example, the acceleration time is set to 6000 seconds, a time scale change from 1
second to 0.01 second will result in a modified acceleration time of 60.00 seconds.
