LSIS SV-IS7 User Manual

Table of Functions
156
DRV Group (PAR  DRV)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial Value
Shift in
Opera-
tion
Control
Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
10
0h110A
Torque
Control
Torque control
0
No
0: No
X
X
X
X
O
O
1
Yes
11
0h110B
Jog
Frequency
Jog frequency
0.5 – maximum
frequency (Hz)
10.00
O
O
O
O
O
O
12
0h110C
Jog Acc Time
Jog run
acceleration time
0 – 600 (sec)
20.0
O
O
O
O
O
O
13
0h110D
Jog Dec Time
Jog run
deceleration time
0 – 600 (sec)
30.0
O
O
O
O
X
X
14
0h110E
Motor
Capacity
Motor capacity
0:0.2kW, 1:0.4kW
2:0.75kW,
3:1.5kW
4:2.2kW,
5:3.7kW
6:5.5kW,
7:7.5kW
8:11kW,
9:15kW
10:18.5kW, 11:22kW
12:30kW, 13:37kW
14:45kW, 15:55kW
16:75kW, 17:90kW
18:110kW, 9:132kW
20:160kW, 1:185kW
22:220kW,23:280kW
24:315kW,25:375kW
26:450kW
Dependent on
inverter capacity
X
O
O
O
O
O
15
0h110F
Torque Boost
Torque boost
method
0
Manual
0:Manual
X
O
X
X
X
X
1
Auto
2
Advanced Auto
16
Not
e2)
0h1110
Fwd Boost
Forward torque
boost
0 – 15 (%)
Below 75kW
2.0
X
O
X
X
X
X
Above 90kW
1.0
17
0h1111
Rev Boost
Reverse torque
boost
0 – 15(%)
Below 75kW
2.0
X
O
X
X
X
X
Above 90kW
1.0
18
0h1112
Base Freq
Base frequency
30 – 400 (Hz)
60.00
X
O
O
O
O
O
19
0h1113
Start Freq
Starting
frequency
0.01 – 10 (Hz)
0.50
X
O
X
X
X
X
20
0h1114
Max Freq
Maximum
frequency
40 – 400
60.00
X
O
O
O
O
O
21
0h1115
Hz/Rpm Sel
Speed unit
selection
0
Hz Display
0:Hz
O
O
O
O
O
O
1
Rpm Display
25
0h1119
Output Freq
Output speed
monitoring
0-Max Frequency
0.00
O
O
O
O
O
O
* The grey cells indicate a hidden code which is only visible when setting a code.
Note 2)
DRV-16–17 code is displayed only when DRV-15 (Torque Boost) code value is “Manual”.
