LSIS SV-IS7 User Manual

Table of Functions
Function
Table
159
BAS Group (PAR  BAS)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
06
0h1206
Trq 2nd Src
Second torque
command
source
1
Keypad-2
0:Keypad-1
O
X
X
X
O
O
2
V1
3
I1
4
V2
5
I2
6
Int 485
7
Encoder
8
FieldBus
9
PLC
10
Synchro
11
Binary Type
12
Keypad-2
07
0h1207
V/F Pattern
V/F pattern
options
0
Linear
0:Linear
X
O
O
X
X
X
1
Square
2
User V/F
3
Square2
08
0h1208
Ramp T
Mode
Acc/Dec
standard
frequency
0
Max Freq
0:Max Freq
X
O
O
O
X
X
1
Delta Freq
09
0h1209
Time Scale
Time scale
settings
0
0.01 sec
1:0.1 sec
X
O
O
O
X
X
1
0.1 sec
2
1 sec
10
0h120A
60/50 Hz Sel
Input power
frequency
0
60 Hz
0:60 Hz
X
O
O
O
O
O
1
50 Hz
11
0h120B
Pole Number
Number of
motor poles
248
Dependent on
inverter capacity
X
O
O
O
O
O
12
0h120C
Rated Slip
Rated slip speed
0 – 3000 (rpm)
X
O
O
O
O
O
13
0h120D
Rated Curr
Motor rated
current
1 – 1000 (A)
X
O
O
O
O
O
14
0h120E
Noload Curr
Motor
no-load current
0.5 – 1000 (A)
X
O
O
O
O
O
15
0h120F
Rated Volt
Motor rated
voltage
180 – 480 (V)
0
X
O
O
O
O
O
16
0h1210
Efficiency
Motor efficiency
70 – 100 (%)
Dependent on
inverter capacity
X
O
O
O
O
O
17
0h1211
Inertia Rate
Load inertia rate
0 – 8
X
O
O
O
O
O
18
0h1212
Trim Power %
Power display
adjustment
70 – 130 (%)
O
O
O
O
O
O
19
0h1213
AC
Input Volt
Input power
voltage
170 – 230 (V)
380 - 480 (V)
220 V
220
O
O
O
O
O
O
44x0 V
380
20
-
Auto
Tuning
Auto tuning
0
None
0:None
X
X
O
O
O
O
1
All
2
ALL(Stdstl)
3
Rs+Lsigma
4
Enc Test
5
Tr
6
Tr(Stdstl)
