LSIS SV-IS7 User Manual

Table of Functions
168
Control Function Group (PAR  CON)
No.
Communi-
cation
Address
LCD Display
Name
Setting Range
Initial Value
Shift in
Opera-
tion
Control Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
31
0h141F
S-Est P Gain2
Sensorless2 speed
estimator proportional
gain 2
1.0 – 1000.0 (%)
Dependent
on motor
capacity
O
X
X
X
X
X
32
0h1420
S-Est I Gain2
Sensorless2 speed
estimator integral gain 2
1.0 – 1000.0 (%)
Dependent
on motor
capacity
O
X
X
X
X
X
34
0h1422
SL2 OVM
Perc
Sensorless2 overvoltage
modulation range
adjustment
100 – 180 (%)
120
X
X
O
X
X
X
35
0h1423
SL2 L-
ExcitLmt
Magnetic flux current
minimum ratio
3~100[%]
10
O
X
X
X
O
X
45
Note18)
0h142D
PG P Gain
PG operation proportional
gain
0 – 9999
3000
O
O
X
X
X
X
46
0h142E
PG I Gain
PG operation integral gain
0 – 9999
50
O
O
X
X
X
X
47
0h142F
PG Slip Max%
PG operation maximum
slip
0 – 200
100
X
O
X
X
X
X
48
-
ACR P Gain
Current controller P gain
0 – 10000
1200
O
X
O
O
O
O
49
-
ACR I Gain
Current controller I gain
0 – 10000
120
O
X
O
O
O
O
51
0h1433
ASR Ref LPF
Speed controller
reference filter
0 – 20000 (ms)
0
X
X
O
O
X
X
52
0h1434
Torque Out
LPF
Torque controller
output filter
0 – 2000 (ms)
0
X
X
X
X
O
O
53
0h1435
Torque Lmt
Src
Torque limit
setting options
0
Keypad-1
0:Keypad-1
X
X
X
X
O
O
1
Keypad-2
2
V1
3
I1
4
V2
5
I2
6
Int 485
7
Encoder
8
FieldBus
9
PLC
10
Synchro
11
Binary Type
54
Note19)
0h1436
FWD +Trq
Lmt
Forward offsetting
torque limit
0 – 200 (%)
180.0
O
X
X
X
O
O
55
0h1437
FWD –Trq
Lmt
Forward offsetting
torque limit
0 – 200 (%)
180.0
O
X
X
X
O
O
56
0h1438
REV +Trq Lmt
Reverse regenerative
torque limit
0 – 200 (%)
180.0
O
X
X
X
O
O
57
0h1439
REV –Trq Lmt
Reverse regenerative
torque limit
0 – 200 (%)
180.0
O
X
X
X
O
O
* The grey cells indicate a hidden code which is only visible when setting a code.
Note 18)
CON-45 – 47 are displayed when the Encoder module is installedand Control mode is set as “V/F
PG”.
Note 19)
CON-54 – 57 are displayed only when DRV-09 (Control Mode) is set as “Sensorless-1, 2” or
“Vector”. In addition, the initial value of the torque limit is changed to 150% when the ADV-74
RegenAvd Level function is set.
