LSIS SV-IS7 User Manual

Table of Functions
Function
Table
177
Output Terminal Block Function Group (PAR  OUT)
No.
Communi
-cation
Address
LCD
Display
Name
Setting Range
Initial
Value
Shift in
Opera-
tion
Control
Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
08
0h1608
AO2 Gain
Analog output 2 gain
-1000 – 1000 (%)
80.0
O
O
O
O
O
O
09
0h1609
AO2 Bias
Analog output 2 bias
-100 – 100 (%)
20.0
O
O
O
O
O
O
10
0h160A
AO2 Filter
Analog output 2 filter
0 – 10000 (ms)
5
O
O
O
O
O
O
11
0h160B
AO2
Const %
Analog constant output
2
0 – 100 (%)
0.0
O
O
O
O
O
O
12
0h160C
AO2
Monitor
Analog output 2 monitor
0 – 1000 (%)
0.0
O
O
O
O
O
O
14
Note27)
0h160E
AO3 Mode
Analog output 3 item
0
Frequency
0:
Frequency
O
O
O
O
O
O
1
Current
2
Voltage
3
DC Link Volt
4
Torque
5
Watt
6
Idss
7
Iqss
8
Target Freq
9
Ramp Freq
10
Speed Fdb
11
Speed Dev
12
PID Ref Value
13
PID Fbk Value
14
PID Output
15
Constant
15
0h160F
AO3 Gain
Analog output 3 gain
-1000 – 1000 (%)
100.0
O
O
O
O
O
O
16
0h1610
AO3 Bias
Analog output 3 bias
-100 – 100 (%)
0.0
O
O
O
O
O
O
17
0h1611
AO3 Filter
Analog output 3 filter
0 – 10000 (ms)
5
O
O
O
O
O
O
18
-
AO3
Const %
Analog constant output
3
0 – 100 (%)
0.0
O
O
O
O
O
O
19
0h1613
AO3
Monitor
Analog output 3 monitor
-1000 – 1000 (%)
0.0
O
O
O
O
O
O
20
0h1614
AO4 Mode
Analog output 4 item
0
Frequency
0:
Frequency
O
O
O
O
O
1
Current
2
Voltage
3
DC Link Volt
4
Torque
5
Watt
6
Idss
7
Iqss
8
Target Freq
9
Ramp Freq
10
Speed Fdb
11
Speed Dev
12
PID Ref Value
13
PID Fbk Value
14
PID Output
15
Constant
