LSIS SV-IS7 User Manual

Table of Functions
Function
Table
179
Output Terminal Block Function Group (PAR  OUT)
No.
Communi
-cation
Address
LCD Display
Name
Setting Range
Initial Value
Shift in
Opera-
tion
Control
Mode
V
/
F
S
L
V
C
S
L
T
V
C
T
29
Trip
30
Lost Keypad
31
DB Warn %ED
32
ENC Tune
33
ENC Dir
34
On/Off Control
35
BR Control
36
KEB Operating
37
Fire Mode
38
Run2
41
0h1629
DO Status
Multi-function output
monitoring
-
000
X
-
-
-
-
-
50
0h1632
DO On Delay
Multi-function output
On delay
0 – 100 (sec)
0.00
O
O
O
O
O
O
51
0h1633
DO Off Delay
Multi-function output
Off delay
0 – 100 (sec)
0.00
O
O
O
O
O
O
52
0h1634
DO
NC/NO Sel
Multi-function output
contact point
selection
Q1,Relay2,Relay1
000
X
O
O
O
O
O
0
A contact point
(NO)
1
B contact point
(NC)
53
0h1635
TripOut OnDly
Failure output On
delay
0 – 100 (sec)
0.00
O
O
O
O
O
O
54
0h1636
TripOut OffDly
Failure output Off
delay
0 – 100.00 (sec)
0.00
O
O
O
O
O
O
55
0h1637
TimerOn Delay
Timer On delay
0 – 100.00 (sec)
0.00
O
O
O
O
O
O
56
0h1638
TimerOff Delay
Timer Off delay
0 – 100.00 (sec)
0.00
O
O
O
O
O
O
57
0h1639
FDT Frequency
Detected frequency
0 – maximum
frequency (Hz)
30.00
O
O
O
O
O
O
58
0h163A
FDT Band
Detected frequency
width
0 – maximum
frequency (Hz)
10.00
O
O
O
O
O
O
59
0h163B
TD Level
Detected torque
amount
0 – 150 (%)
100
O
X
X
O
X
O
60
0h163C
TD Band
Detected torque
width
0 – 10 (%)
5.0
O
X
X
O
X
O
* The grey cells indicate a hidden code which is only visible when setting a code.
