Multi-
function
terminal
(8 EA)
P1–P8*
Select NPN (Sink) or PNP (Source) mode.
• Forward direction operation
• Reset
• Emergency stop
• Multi-step speed frequency-
high/med/low
• DC braking during stop
• Frequency increase
• 3-wire operation
• Acceleration/deceleration/stop
• Operation by keypad input
during an operation by
network communication
• Reverse direction
operation
• External trip
• Jog operation
• Multi-step acc/dec-
high/med/low
• Second motor
selection
• Frequency reduction
• Transition from PID
to general operation
• Analog command
frequency fix
Multi-
function
open
collector
terminal
Fault output and inverter operation
status output
Less than DC 26 V, 100 mA
Multi-
function
relay
terminal
N.O.: Less than AC 250 V
1A, DC 30 V, 3A
N.C.: Less than AC 250 V
1A, DC 30 V 1A
DC 0–10 V, 0–20 mA: Select output type from frequency, current,
voltage, or DC voltage.
* Set the Input Group codes IN-65 through IN-72 to configure the multi-function terminal functions.
