Installing the Inverter
32
SV1850-2200iS7 (400 V, IP00 Type)
Units: mm (inch)
Inverter Capacity
W1
W2
W3
H1
H2
H3
D1
A
B
C
SV1850/
2200iS7-4
690
(27.16)
581
(22.87)
528
(20.79)
1078
(42.44)
1043.5
(41.08)
25.5
(1.00)
450
(17.72)
14
(0.55)
15
(0.59)
M20
