Connecting the Cables
Connecting
the Cables
55
Asymmetrical Grounding Connection
One phase of
a delta
connection is
grounded
Intermediate
grounding
point on one
phase of a
delta
connection
The end of a
single phase is
grounded
A 3-phase
connection
without
grounding
