Page 136
MAINTENANCE
117
Figure 117 — MACK Fuel Filtration System (AC Engine)
1. Fuel Supply Pump with Filter Mounting Provision
2. Fuel Filter Element
3. Pre-Pump Filter (Used in production prior to
December 22, 2003; replaced by a plug and O-ring in later
production.)
5-111.bk Page 136 Monday, July 10, 2006 2:26 PM
