SPECIFICATIONS
Page 469
ASET™ AC-460(E) (CEGR) ECONODYNE
— Speed Range — 1200–1800 rpm
— Power at Governed Speed — 460 hp
(343 kW) at 1800 rpm
— Peak Power — 460 hp (343 kW) at
1600–1800 rpm
— Maximum Torque — 1,660 lb-ft
(2 251 N폷m) at 1200 rpm
— Torque Rise — 24 percent
ASET™ AC-460(P) (CEGR) ECONODYNE
— Speed Range — 1200–1800 rpm
— Power at Governed Speed — 480 hp
(359 kW) at 1800 rpm
— Peak Power — 487 hp (363 kW) at
1600 rpm
— Maximum Torque — 1,660 lb-ft
(2 251 N폷m) at 1200 rpm
— Torque Rise — 19 percent
Material and Dimensional Data
WEIGHTS AND DIMENSIONS
COMPONENT FEATURES AND MATERIALS
Item Specification
Weight (wet) — includes oil and coolant 2340 lbs. (1062 kg)
Weight (dry) 2290 lbs. (1039 kg)
Displacement 728 cu. in. (12 L)
Bore and stroke 4-7/8 in. x 6-1/2 in. (124 mm x 165 mm)
Coolant capacity 13 qts. (12.3 L)
Sleeve design Wet/dry
Compression ratio 16:1
Fasteners and threads Metric
Flywheel housing — standard Aluminum
Flywheel housing — optional (required for certain engine and
transmission combinations)
Ductile iron
Item Description
Air compressor Flange-mounted, drive coupling, oil-lubricated and
water-cooled from engine; Bendix or Meritor WABCO
Bearings — connecting rod Steel back, cast copper-lead intermediate layer, lead-tin
overlay, deltawall
Bearings — main Steel back, cast copper-lead intermediate layer, lead-tin
overlay
Camshaft Carbon steel with induction-hardened journals and lobes,
gear driven
Coolant conditioner Spin-on type, disposable, head assembly attaches to front
cover
Connecting rods Forged steel, I-beam type with tapered pin end, 35-degree
cap angle, 10.4 inches (264 mm) center-to-center length
Crankshaft Drop-forged, medium carbon steel, elotherm-hardened
journals and fillets, eight integral counterweights, 3.25-inch
(83 mm) pin journal diameter, 4.5-inch (114 mm) main journal
diameter
Cylinder block Alloyed gray cast iron
