REPAIR INSTRUCTIONS, PART 1
Page 171
165
Figure 165 — Rocker Arm Shaft Assembly with J-Tech™ Engine Brake
1. Cylinder Head Cover
2. Spacer
3. Capscrew
4. Spherical Jam Nut
5. Exhaust Adjusting Screw
6. Standard Adjusting Screw and Jam Nut (Inlet Valves)
7. Cylinder Head
8. Exhaust Valve Yokes
9. Actuator Pin Assembly
10. Rocker Arm Shaft Assembly
11. Engine Brake Oil Supply Screw
12. Slave Piston Adjusting Screw
13. Engine Brake Assembly
