REPAIR INSTRUCTIONS, PART 1
Page 265
295
Figure 295 — Valve Rocker Arm Shaft Assembly (without Engine Brake)
1. Flat Washer and C-Clip
2. Spring Washer
3. Locating Screw and Lock Washer
4. Standard Adjusting Screws and Jam Nuts
5. Exhaust Rocker Arm
6. Mounting Bracket
7. Inlet Rocker Arm
8. Shaft
9. Capscrews
5-111.bk Page 265 Monday, July 10, 2006 2:26 PM
