REPAIR INSTRUCTIONS, PART 1
Page 349
414
Figure 414 — EGR Valve Installation
415
Figure 415 — EGR Valve, Installed
1. EGR Valve Assembly 2. Exhaust Manifold
1. EGR Valve
2. Electrical Connection
3. Oil Return Line
4. Mounting Studs/Nuts
5. EGR Hot Tube
5-111.bk Page 349 Monday, July 10, 2006 2:26 PM
