Page 388
REPAIR INSTRUCTIONS, PART 2
462
Figure 462 — EECU Removal/Installation
6. Disconnect the two harness leads from the
EGR MASS Flow module mounted to the
back side of the cooling plate (Figure 463).
463
Figure 463 — EGR MASS Flow Module Connections
1. Cooling Plate
2. Retaining Bolt
3. EECU
1. Module Connections 2. Cooling Plate
5-111.bk Page 388 Monday, July 10, 2006 2:26 PM
