REPAIR INSTRUCTIONS, PART 2
Page 407
491
Figure 491 — Cool Tube Clamp Installation
5. Start the engine and allow it to warm up.
Check for leaks in the EGR system.
6. Stop the engine. Allow it to cool down and
then retorque the clamps.
1. Mounting Bolts 2. Clamps, Upper and Lower Halves
5-111.bk Page 407 Monday, July 10, 2006 2:26 PM
