BRAKE COMPONENTS — MACK POWERLEASH™
Engine Brake Hydraulic Actuator Jam Nut 45 61
Rocker Arm Adjusting Screw Nut 45 61
Rocker Arm Shaft Locating Screw (1 Per Shaft Assembly) 23 31
Rocker Arm Bracket-to-Rocker Arm Shaft Screw (2 Per Shaft Assembly) 18 24
Rocker Arm Bracket-to-Cylinder Head Screw 45 61
CAMSHAFT
Camshaft Thrust Washer-to-Cylinder Block Screw 15 20
CONNECTING ROD
Connecting Rod Screw Angle Torque 30 + 90° 41 + 90°
CRANKSHAFT
Vibration Damper Hub-to-Crank Screw 360 490
Vibration Damper-to-Hub Screw 45 61
CYLINDER BLOCK
Main Bearing Capscrew (See “NOTE 2 — MAIN BEARING CAP
INSTALLATION” on page 488.)
210 285
Cylinder Block Main Bearing Cap Buttress Screw (See “NOTE 2 — MAIN
BEARING CAP INSTALLATION” on page 488.)
95 128
CYLINDER HEAD
Cylinder Head Capscrew* (See “NOTE 3 — CYLINDER HEAD TORQUING” on
page 488.)
205 278
Cylinder Head Cover Screw 16 22
Inlet Manifold-to-Cylinder Head Screw 40 55
ELECTRONIC UNITS
EECU Cooler Plate-to-Isolator Nut 108 lb-in 12
EECU Isolator-to-Inlet Manifold 16 22
EECU Harness Clamp 11 15
EECU Cooler Plate Swivel Fittings 20 27
EECU-to-Cooler Plate Screw 96 lb-in 11
Electronic Unit Pump Terminal Screw 13 lb-in ± 2 lb-in 1.5 ± 0.2
Electronic Unit Pump-to-Cylinder Block Screw 60 81
EGR COMPONENTS
EGR Mixer-to-Manifold Screw 40 55
EGR Mixer Support Bracket Screw 40 55
EGR Mass Flow System (MFS) Module Screw 48 lb-in 5.5
EGR Valve Mounting Nuts 40 55
EGR Valve and Manifold Heat Shield Screws:
M10 20 27
M8 811
EGR Cooler Inlet Piping (hot side) Clamps 110 lb-in 12.4
EGR Cooler Outlet Piping (cold side) Clamps 110 lb-in 12.4
Fastener Name
Torque
Lb-Ft N폷m
