SPECIFICATIONS
TORQUE SPECIFICATIONS FOR ENGINE-MOUNTED SENSORS
ASET™ AC ENGINE-MOUNTED SENSORS
Overtorquing a sensor or sensor mounting screw
can result in sensor breakage or thread damage.
Description Sensor and Sensor Mounting Hardware Sensor Threads Mounting Torque
Air Temperature Sensor
(wide range and fast
response)
64MT450 sensor only; sensor is used in three locations:
앫 Compressor discharge temperature
앫 CMCAC outlet temperature
앫 Inlet manifold temperature
Reinstallation of this sensor requires application of
stainless steel pipe thread sealing tape. This tape is
identified as Mill-Ross type TF5-28, catalog number
70981-st, size 1/2" x 260".
23 lb-ft (31 N폷m)
Ambient Air
Temperature Sensor
(mounted at front of
chassis)
64MT2118M Press Fit (Snap In) N/A
Boost Air Temperature
Sensor
64MT445 sensor only (no washer required) 1/2-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
Boost Pressure Sensor 46MT446 1/4-inch NPT 18 lb-ft (24 N폷m)
Coolant Temperature
Sensor (dash gauge)
64MT2112M sensor only 1/2-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
Coolant Temperature
Sensor (V-MAC III)
64MT2103 sensor only 3/8-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
Engine Position Sensor 64MT348M sensor and 505GC28 P15 and
P30 shims, as required. Sensor is retained
by one 66AM3 capscrew with M6 x 1.0
metric threads.
None 7 lb-ft (10 N폷m)
Engine Speed Sensor 64MT348M sensor and 505GC28 P15 and
P30 shims, as required. Sensor is retained
by one 66AM3 capscrew with M6 x 1.0
metric threads.
None 7 lb-ft (10 N폷m)
Fuel Temperature
Sensor
64MT2103 sensor only 3/8-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
Oil Pressure Sensor 64MT2114 sensor only 1/8-inch NPT English
pipe threads
13.5 lb-ft (18 N폷m)
Oil Temperature Sensor
(electronic dash gauge)
64MT2103 (Sensor mounts in oil filter
pedestal.)
3/8-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
Oil Temperature Sensor
(standard dash gauge)
64T2116 (Sensor mounts in oil filter
pedestal.)
3/8-inch NPT English
pipe threads
23 lb-ft (31 N폷m)
VTG Turbocharger
Position Sensor
Not serviced separately; replaced as part
of actuator assembly.
——
VTG Turbocharger
Wheel-Speed Sensor
64MT457 M10 x 1 9 lb-ft (12 N폷m)
