7B-1190-13645--2 495 OUTBOARD MOTOR INSTALLATION/ATTACHMENTS
2. Remove screw from twist grip.
51603
a
a - Screw
3. Cut sta-strap securing stop switch harness and
remove screw from harness J-clip.
51603
a
b
a - Ties
b - Screw
4. Remove stop switch and twist grip from tiller
handle.
51603
5. Remove throttle cable anchor screws and remove
cable guide.
51602
a
b
a
a - Anchor Screws
b - Throttle Cable Guide
6. Remove allen screw from brass barrel and
remove barrel.
51602
a
b
a - Allen Screw
b - Brass Barrel
