3A-790-13645--2 495 FUEL SYSTEM AND CARBURETION
100-115 (4 cyl.)
(Design 1)
50291
Previous body with rubber check
valve retainers was colored black.
a
b
c
d
e
f
g
h
i
j
a - Body (Opposite Side View)
b - Natural Body (Off White)
c - Rubber Valve
d - Cover (Opposite Side View)
e - Plastic Disc
f - Plastic Check Valve Retainer
g - Two Oil Passage Holes
h - Cast Aluminum Cover
i - One Tab
j - Two Tabs
To Next Page
