Integritest Exacta Filter Integrity Test Instrument
Operating and Maintenance Manual Running a Test 131
Status Message: Meaning
CLEAR Appears when the “clearing upstream” section of a test is
occurring. The “clearing upstream” phase of the test is when
residual fluid is eliminated from the system by pressurizing the
system and pushing it through the filter. This applies to Bubble
Point and diffusion but not the HydroCorr test.
SIZE Appears when the instrument is conducting the upstream gas
volume-sizing phase of the test.
FLOWRATE Indicates that the instrument is conducting a diffusion gas flow
or HydroCorr water flow measurement.
FIND BUBBLE POINT Indicates that the instrument is determining the bubble point.
ENDING Indicates that a test has been completed.
PRINTING
Appears during printing of the test results. If printing is
configured to start automatically, printing will begin. If not,
printing can be started manually.
PASSED Appears at the end of the test, if the filter has passed the
specified test
FAILED Appears at the end of the test, if the filter has not passed the
specified test
TERMINATED
Appears when the user interrupts testing before a completed test
cycle (an abnormal intervention or shutdown).
Note: Error messages may also appear in the status box. See the section titled Test
Status Errors on page 219 for more information.
