Moog Animatics SmartMotor™ Developer's Guide,Rev. L
Page 885 of 909
Status Word 12: User Bits Word 0
Description Bit To Clear Value Bit To read Assign Related Commands
User Bit 0 1 0 RB(12,0) =B(12,0) US(0), UR(0)
User Bit 1 2 1 RB(12,1) =B(12,1) US(1), UR(1)
User Bit 2 4 2 RB(12,2) =B(12,2) US(2), UR(2)
User Bit 3 8 3 RB(12,3) =B(12,3) US(3), UR(3)
User Bit 4 16 4 RB(12,4) =B(12,4) US(4), UR(4)
User Bit 5 32 5 RB(12,5) =B(12,5) US(5), UR(5)
User Bit 6 64 6 RB(12,6) =B(12,6) US(6), UR(6)
User Bit 7 128 7 RB(12,7) =B(12,7) US(7), UR(7)
User Bit 8 256 8 RB(12,8) =B(12,8) US(8), UR(8)
User Bit 9 512 9 RB(12,9) =B(12,9) US(9), UR(9)
User Bit 10 1024 10 RB(12,10) =B(12,10) US(10), UR(10)
User Bit 11 2048 11 RB(12,11) =B(12,11) US(11), UR(11)
User Bit 12 4096 12 RB(12,12) =B(12,12) US(12), UR(12)
User Bit 13 8192 13 RB(12,13) =B(12,13) US(13), UR(13)
User Bit 14 16384 14 RB(12,14) =B(12,14) US(14), UR(14)
User Bit 15 32768 15 RB(12,15) =B(12,15) US(15), UR(15)
Status Word 13: User Bits Word 1
Description Bit To Clear Value Bit To read Assign Related Commands
User Bit 16 1 0 RB(13,0) =B(13,0) US(16), UR(16)
User Bit 17 2 1 RB(13,1) =B(13,1) US(17), UR(17)
User Bit 18 4 2 RB(13,2) =B(13,2) US(18), UR(18)
User Bit 19 8 3 RB(13,3) =B(13,3) US(19), UR(19)
User Bit 20 16 4 RB(13,4) =B(13,4) US(20), UR(20)
User Bit 21 32 5 RB(13,5) =B(13,5) US(21), UR(21)
User Bit 22 64 6 RB(13,6) =B(13,6) US(22), UR(22)
User Bit 23 128 7 RB(13,7) =B(13,7) US(23), UR(23)
User Bit 24 256 8 RB(13,8) =B(13,8) US(24), UR(24)
User Bit 25 512 9 RB(13,9) =B(13,9) US(25), UR(25)
User Bit 26 1024 10 RB(13,10) =B(13,10) US(26), UR(26)
User Bit 27 2048 11 RB(13,11) =B(13,11) US(27), UR(27)
User Bit 28 4096 12 RB(13,12) =B(13,12) US(28), UR(28)
User Bit 29 8192 13 RB(13,13) =B(13,13) US(29), UR(29)
User Bit 30 16384 14 RB(13,14) =B(13,14) US(30), UR(30)
User Bit 31 32768 15 RB(13,15) =B(13,15) US(31), UR(31)
Appendix: Status Word 12: User Bits Word 0
