5 - 188 WiNG 5.6 Access Point System Reference Guide
Figure 5-123 Advanced Profile Configuration- MINT Protocol screen - Add IP MiNT Link field
11. Set the following Link IP parameters to complete the MINT network address configuration:
IP Define the IP address used by peer access points for interoperation when supporting
the MINT protocol.
Port Select this option to specify a custom port for MiNT links. Use the spinner control to
define the port number (from 1 - 65,535).
Routing Level Use the spinner control to define a routing level of either 1 or 2.
Listening Link Specify a listening link of either 0 or 1. UDP/IP links can be created by configuring a
matching pair of links, one on each end point. However, that is error prone and does
not scale. So UDP/IP links can also listen (in the TCP sense), and dynamically create
connected UDP/IP links when contacted.
Forced Link Select this option to specify the MiNT link as a forced link.
Link Cost Use the spinner control to define a link cost from 1 - 10,000. The default value is 100.
Hello Packet Interval Set an interval in either Seconds (1 - 120) or Minutes (1 - 2) for the transmission of
hello packets. The default interval is 15 seconds.
Adjacency Hold Time Set a hold time interval in either Seconds (2 - 600) or Minutes (1 - 10) for the
transmission of hello packets. The default interval is 46 seconds.
IPSec Secure Select this option to use a secure link for IPSec traffic. This setting is disabled by
default. When enabled, both the header and the traffic payload are encrypted.
