5 - 208 WiNG 5.6 Access Point System Reference Guide
Figure 5-138 Certificate Management - Export RSA Key screen
12. Define the following configuration parameters required to export a RSA key:
Key Name Enter the 32 character maximum name assigned to the RSA key.
Key Passphrase Define the key passphrase used by both the access point and the server. Select the Show
option to expose the actual characters used in the passphrase. Leaving the Show option
unselected displays the passphrase as a series of asterisks “*”.
URL Provide the complete URL to the location of the key.
Protocol If selecting Advanced, select the protocol used for exporting the RSA key. Available
options include:
• tftp
• ftp
• sftp
• http
•cf
•usb1
•usb2
•usb3
•usb4
Port If selecting Advanced, use the spinner control to set the port. This option is not valid for
cf, usb1, usb2, usb3 and usb4.
