5 - 244 WiNG 5.6 Access Point System Reference Guide
38. Configure the OSPF Authentication Type settings by selecting from the drop-down list. The available options are None,
null, simple-password and message-digest.
39. Refer the following to configure MD5 Authentication keys. Select the + Add Row button to add a row to the table.
40. Select the OK button located at the bottom right of the screen to save the changes and overrides to the Security screen.
Select Reset to revert to the last saved configuration.
5.4.5.3.3 Port Channel Override Configuration
Profile Interface Override Configuration
Access points can have their port channel configurations overridden if a portion of the configuration is no longer relevant to
the access point’s deployment objective.
To override a port channel configuration for an access point profile:
1. Select the Configuration tab from the Web UI.
2. Select Devices from the Configuration tab.
3. Select Device Overrides
4. Select a target device from the device browser in the lower, left-hand, side of the UI.
5. Expand the Interface menu and select Port Channels.
Figure 5-160 Device Overrides - Port Channels screen
6. Refer to the following to review existing port channel configurations and their current status:
Key ID Set the unique MD5 Authentication key ID. The available key ID range is 1 - 255.
Password Set the OSPF password. This value is displayed as “asterisk” (*). Select Show to expose the
characters comprising the password.
Name Displays the port channel’s numerical identifier assigned to it when it was created. The
numerical name cannot be modified as part of the edit process.
Type Displays whether the type is port channel.
