Device Configuration 5 - 269
3. Select a target device from the device browser in the lower, left-hand, side of the UI.
4. Select Network to expand its sub menu options.
5. Select L2TP V3.
Figure 5-173 Device Overrides - Network - L2TPv3 screen, General tab
6. Set the following General Settings for an L2TPv3 profile configuration:
NOTE: A blue override icon (to the left of a parameter) defines the parameter as having
an override applied. To remove an override, go to the Basic Configuration screen’s Device
Overrides field and select Clear Overrides. This will remove all overrides from the
device.
Host Name Define a 64 character maximum hostname to specify the name of the host that sent tunnel
messages. Tunnel establishment involves exchanging 3 message types (SCCRQ, SCCRP
and SCCN) with the peer. Tunnel IDs and capabilities are exchanged during the tunnel
establishment with the host.
Router ID Set either the numeric IP address or the integer used as an identifier for tunnel AVP
messages. AVP messages assist in the identification of a tunnelled peer.
UDP Listen Port Select this option to set the port used for listening to incoming traffic. Select a port from
1,024 - 65,353.
Tunnel Bridging Select this option to enable or disable bridge packets between two tunnel end points. This
setting is disabled by default.
