5 - 270 WiNG 5.6 Access Point System Reference Guide
7. Set the following Logging Settings for a L2TPv3 profile configuration:
8. Select the L2TPv3 Tunnel tab.
Figure 5-174 Device Overrides - Network - L2TPv3 screen, L2TPv3 tunnel tab
9. Set the following for an L2TPv3 profile configuration:
Enable Logging Select this option to enable the logging of Ethernet frame events to and from bridge VLANs
and physical ports on a defined IP address, host or router ID. This setting is disabled by
default.
IP Address Optionally use a peer tunnel ID address to capture and log L2TPv3 events.
Hostname If not using an IP address for event logging, optionally use a peer tunnel hostname to capture
and log L2TPv3 events.
Router ID If not using an IP address or a hostname for event logging, use a router ID to capture and log
L2TPv3 events.
Name Displays the name of each listed L2TPv3 tunnel assigned upon creation.
Local IP Address Lists the IP address assigned as the local tunnel end point address, not the interface IP
address. This IP is used as the tunnel source IP address. If this parameter is not specified,
the source IP address is chosen automatically based on the tunnel peer IP address.
MTU Displays the maximum transmission unit (MTU) size for each listed tunnel. The MTU is the
size (in bytes) of the largest protocol data unit that the layer can pass between tunnel
peers.
Use Tunnel Policy Lists the L2TPv3 tunnel policy assigned to each listed tunnel.
Local Hostname Lists the tunnel specific hostname used by each listed tunnel. This is the hostname
advertised in tunnel establishment messages.
Local Router ID Specifies the router ID sent in the tunnel establishment messages.
Establishment Criteria Specifies the criteria that should be met for a tunnel between two peers to be created and
maintained.
