6 - 78 WiNG 5.6 Access Point System Reference Guide
6. Refer to the Calibration Assignment field to define whether Smart RF Calibration and radio grouping is conducted by the
floor the access point is deployed on or building in its entirety. Both options are disabled by default.
7. Select OK to update the access point’s Smart RF Basic configuration. Select Reset to revert to the last saved configuration.
The Smart RF policy can be invoked at any point in the configuration process by selecting Activate SMART RF Policy
from the upper, left-hand side, portion of the access point user interface.
8. Select Channel and Power. Ensure the Activate SMART RF Policy remains selected so the screen’s parameters can be
updated.
Use the Channel and Power screen to refine Smart RF power settings over both the 5.0 GHz and 2.4 GHz radio bands and
select channel settings in respect to the access point’s channel usage.
Figure 6-33 SMART RF - Channel and Power screen
9. Refer to the Power Settings field to define Smart RF recovery settings for the access point’s 5.0 GHz (802.11a) and 2.4
GHz (802.11bg) radio.
NOTE: The Power Settings and Channel Settings parameters are only enabled
when Custom is selected as the Sensitivity setting from the Basic Configuration screen.
5 GHz Minimum Power Use the spinner control to select a 1 - 20 dBm minimum power level for Smart RF to assign
to a radio in the 5.0 GHz band. The default setting is 4 dBm.
5 GHz Maximum Power Use the spinner control to select a 1 - 20 dBm maximum power level Smart RF can assign
a radio in the 5.0 GHz band. The default setting is 17 dBm.
