6 - 90 WiNG 5.6 Access Point System Reference Guide
Figure 6-40 MeshConnex - Security screen
9. Refer to the Select Authentication field to define an authentication method for the mesh policy.
10. Set the following Key Settings for the mesh point:
11. Set the following Key Rotation for the mesh point:
12. Select OK to save the changes made to the configuration. Select Reset to revert to the last saved configuration.
13. Select the Radio Rates tab.
Security Mode Select a security authentication mode for the mesh point. Select none to set no
authentication for the mesh point. Select psk to set a pre-shared key as the authentication
for the mesh point. If psk is selected enter a pre-shared key in the Key Settings field.
Pre-Shared Key When the security mode is set as psk, enter a 64 character HEX or an 8-63 ASCII character
passphrase used for authentication on the mesh point.
Unicast Rotation Interval Define an interval for unicast key transmission in seconds (30 - 86,400).
Broadcast Rotation
Interval
When enabled, the key indices used for encrypting/decrypting broadcast traffic will be
alternatively rotated based on the defined interval. Define an interval for broadcast key
transmission in seconds (30 - 86,400). Key rotation enhances the broadcast traffic security
on the WLAN.
