Network Configuration 7 - 7
Figure 7-4 Policy Based Routing screen - General tab
13. Set the following General PBR configuration settings:
14. Select OK to save the updates to the route-map general configuration. Select Reset to revert to the last saved
configuration.
Logging Select this option to log events generated by route-map configuration rule enforcement.
This setting is disabled by default.
Local PBR Select this option to implement policy based routing for this access point’s packet traffic.
This setting is enabled by default, so the match and action clauses defined within the
Route Maps tab are implemented until disabled using this setting.
Use CRM Select the Use CRM (Critical Resource Management) option to monitor access point link
status. Selecting this option determines the disposition of the route-map next hop via
monitored critical resources. Link monitoring is used to determine a potential failover to
the secondary next hop. This setting is enabled by default.
