7 - 6 WiNG 5.6 Access Point System Reference Guide
10. Set the following Action Clauses to determine the routing function performed when a packet satisfies match criteria.
Optionally fallback to destination based routing if no hop resource is available.
11. Select OK to save the updates to the route-map configuration. Select Reset to revert to the last saved configuration.
12. Select the General tab from within the Policy Based Routing screen.
Incoming Interface Select this option to enable radio buttons used to define the interfaces required to receive
route-map packets. Use the drop-down menu to define either the access point’s wwan1
or pppoe1 interface. Neither is selected by default. Or, select the VLAN ID option to define
the access point VLAN to receive route-map-packets.
Next Hop (Primary) Define a first hop priority request. Set either the IP address of the virtual resource or select
the Interface option and define either a wwan1, pppoe1 or a VLAN interface. In the
simplest terms, if this primary hop resource is available, its used with no additional
considerations.
Next Hop (secondary) If the primary hop request were unavailable, a second resource can be defined. Set either
the IP address of the virtual resource or select the Interface option and define either a
wwan1, pppoe1 or a VLAN interface.
Default Next Hop If a packet subjected to PBR does not have an explicit route to the destination, the
configured default next hop is used. This value is set as either the IP address of the next
hop or the outgoing interface. Only one default next hop can be defined. The difference
between the next hop and the default next-hop is in case of former, PBR occurs first, then
destination based routing. In case of the latter, the order is reverse. Set either the next
hop IP address or define either a wwan1, pppoe1 or a VLAN interface.
Use Destination Routing It may be a good idea to select this option to default back to destination based routing if
none of the defined hop resources are reachable. Packets are dropped if a next hop
resource is unavailable and fallback to destination routing is disabled. This option is
enabled by default.
Mark Select this option and use the spinner control to set IP DSCP bits for QoS using an ACL.
The mark action of the route maps takes precedence over the mark action of an ACL.
