Quick Start 3 - 29
3.1.2.4 Radio Configuration
Advanced Setup Wizard
Use the Radio Configuration screen to define radio support for the 2.4 GHz radio band, 5.0 GHz radio band or set the radio
as a dedicated sensor.
Figure 3-18 Initial Setup Wizard - Radio Configuration screen of the Advanced Setup Wizard
1. Set the following for each radio:
• Configure as a Data Radio - Select this option to dedicate this radio to WLAN client support in the selected 2.4 GHz
or 5.0 GHz radio band.
• Radio Frequency Band - Select the 2.4 GHz or 5.0 GHz radio band to use with the radio when selected as a Data Radio.
The selected band is used for WLAN client support. Consider selecting one radio for 2.4 GHz and another for
5.0 GHz support (if using a dual or three radio model) when supporting clients in both the 802.11bg and 802.11n bands.
NOTE: The Radio Configuration screen displays separate configurable fields for each
access point radio. Supported access point models can have from one to three (AP7131)
radios. The ADSP Sensor Server field displays at the bottom of the screen only if one
of the radios has been dedicated as a sensor.
