Operations 12 - 31
Figure 12-43 AP Upgrade screen - AP Image File
9. Select the Device Image File tab and refer to the following configuration parameters:
Device Image Type Select the access point model to specify which model should be available to upgrade.
Upgrades can only be made to the same access point model. For example, an AP6532
firmware image cannot be used to upgrade an AP7131 model access point. For that
reason, the drop-down menu will only display the model deployed.
URL Enter a URL pointing to the location of the image file.
Advanced/Basic Select Advanced to list additional options for the image file location including
protocol, host and path. Additional options display based on the selected protocol.
Select Basic to display only the URL field.
