Operations 12 - 45
Figure 12-55 Devices Captive Portal Pages - CP Page Image File screen
10. Use the Captive Portal List drop-down list to select the captive portal configuration to upload to the adopted access
points.
11. Set the following file transfer configuration parameters of the required file transfer activity:
Protocol If Advanced is selected, choose the protocol for file management. Available options
include:
• tftp
• ftp
• sftp
• http
•cf
•usb1
•usb2
•usb3
•usb4
This parameter is required only when Server is selected as the Source and Advanced
is selected.
Port If Advanced is selected, specify the port for transferring files. This option is not
available for cf, usb1, usb2, usb3 and usb4. Enter the port number directly or use the
spinner control.
