12 - 58 WiNG 5.6 Access Point System Reference Guide
7. Define the following configuration parameters required for the import of the RSA key:
8. Select OK to import the defined RSA key. Select Cancel to revert the screen to its last saved configuration.
9. To optionally export a RSA key to a remote location, select the Export button from the RSA Keys screen.
10. Export the key to a redundant RADIUS server so it can be imported without generating a second key. If there’s more than
one RADIUS authentication server, export the certificate and don’t generate a second key unless you want to deploy two
root certificates.
Key Name Enter the 32 character maximum name assigned to identify the RSA key.
Key Passphrase Define the key used by the server (or repository) of the target RSA key. Select the Show
textbox to expose the actual characters used in the passphrase. Leaving the option
unselected displays the passphrase as a series of asterisks “*”.
URL Provide the complete URL to the location of the RSA key. If needed, select Advanced to
expand the dialog to display network address information to the location of the target key.
The number of additional fields that populate the screen is dependent on the selected
protocol.
Protocol Select the protocol used for importing the target key. Available options include:
• tftp
• ftp
• sftp
• http
•cf
•usb1
•usb2
•usb3
•usb4
Port Use the spinner control to set the port. This option is not valid for cf and usb1 - 4.
IP Address Enter IP address of the server used to import the RSA key. This option is not valid for cf
and usb1 - 4.
Hostname Provide the hostname of the server used to import the RSA key. This option is not valid for
cf and usb1 - 4.
Username/Password These fields are enabled if using ftp or sftp protocols. Specify the username and the
password for that username to access the remote servers using these protocols.
Path Specify the path to the RSA key. Enter the complete relative path to the key on the server.
