Dashboard 4 - 9
Figure 4-10 Dashboard - Inventory tab - Wireless Clients field
Information within the Wireless Clients field is presented in two tables. The first table lists the total number of wireless
clients managed by this access point. The second table lists an ordered ranking of radios based on their supported client count.
Use this information to assess if an access point managed radio is optimally deployed in respect to its radio type and intended
client support requirements.
4.1.1.2.4 Clients by Radio Type
Inventory
The Clients by Radio Type field displays a bar graph illustrating the number of connected clients currently operating on
supported radio bands.
Figure 4-11 Dashboard - Inventory tab - Clients by Radio Type field
For 5.0 GHz, clients are displayed supporting the 802.11a and 802.11an radio bands. For 2.4 GHz, clients are displayed
supporting the 802.11b, 802.11bg, and 802.11bgn radio bands. Use this information to determine if all the access point’s client
radio bands are optimally supported for the access point’s radio coverage area.
NOTE: AP6522, AP6522M, AP6532, AP6562, AP8132, AP8232, AP7131, AP7161 and
AP7181 model access points can support up to 256 client connections to a single access
point. AP6511 and AP6521 model access points (both single radio models) can support
up to 128 client connections per access point.
