(1) Head ID
In this menu, you can enter a head ID. The head ID is used to determine the printer head-driving voltage
and perform temperature correction.
After a head ID has been entered, the system shifts to the Ink Charge menu.
* HeadRank * * HeadRank *
ID1 – H + Head ID input
1BZ3E3ECVXUWWQQ -
↓ ENTER
Incorrectly entered : Error
Press “ENTER” to re-enter
* HeadRank *
ID1 - L +
00Y0IZVTTR 40UWJB -
↓ ENTER
* HeadRank *
Update Parameter
↓ ENTER
* HeadRank *
Updating Parameter
↓
* HeadRank * CANCEL
Ink charge [ENTER]
→ → → →
Initial charge is not performed
Rank input value is updated
↓ ENTER
* Charge *
[1] No Cartridge
↓
* Charge *
Ink Charge
